SCOPE R4.G - Gravel Wheelset

SCOPE R4.G - Gravel Wheelset

€1.698,00
€1.698,00
Sold out
Tax included. Shipping calculated at checkout.

Size Guide

  • This sizing is how we believe your product should fit for Apparel Only.
  • If you get advised two sizes, you may either choose the smaller one for an extra racey fit, or the larger one for a more comfortable fit.
  • Do you prefer a more loose/comfortable fit? Order one size up!
  • If you're still doubting your size, don't hesitate to contact us via the chat or contact form below.
  • Always try on your jersey wearing cycling bibs, so as to prevent it looks awkwardly short/tight.

By adopting the proven rim profiles of the Artech series (without the Aeroscales) the R4.G delivers best in benchmark-tested aerodynamic performance. With steel spokes and a total weight of just 1439 grams, it is the ultimate gravel wheelset, built to excel both in the heat of competition and in the demands of daily training.

Beyond its low weight and aerodynamic advantage, the R4.G combines exceptional lateral stiffness with uncompromising durability. Its 28 mm internal width hookless rim is aerodynamically optimized for 40 mm tubeless tires, offering the perfect balance of rolling resistance, efficiency, and comfort. Meanwhile, the mechanical labyrinth system protects against dirt ingress, ensuring long-term reliability and consistent performance.

Features:

Algorithm Enhanced Aerodynamics

The shape of our rims is defined by our Algorithm Enhanced Aerodynamics (AEA) technology. This algorithm optimizes the most aerodynamic rim-profile guaranteeing optimal aerodynamic performance.

Lightweight design

With our Local Reinforcement carbon technology, we’ve increased the number of carbon layers around the spoke holes on the inside of the rim. This way we significantly reduce weight while preserving strength and stiffness.

Perfect tire-fit

The unique geometry of our Scope Tubeless System ensures easy mounting, direct inflation, long-lasting pressure and compatibility with all clincher and tubeless tires.

Lightweight and durable

The Diamond Ratchet SL system is made from titanium and finished with a diamond like carbon coating. This results in direct engagement, improved durability, and a significant reduction in weight.



Specifications

General


Total set weight
1439 gram *

Maximum rider weight
No weight limit

Max tire pressure
4.0 bar / 58 psi

* Measured without rim-tape and tubeless valves, variation of ± 5% possible
Rims
Front
Rear
Rim height (mm)
45
45
External rim width (mm)
38
38
Internal rim width (mm)
28
28
Tubeless (ready)*
Yes
Yes
Hooked
No - hookless
No - hookless
Optimum tire width (mm)
40
40
Tire width compatibility (mm)
35 - 65
35 - 65
* Compatible with hookless approved tubeless tires
Hubs
Front
Rear
Hubs
Scope R-Series
Scope R-Series
Bearings**
2 X 61803 - SKF
3 X 61803, 1 X 61903 - SKF
Engagement system

36T Diamond Ratchet SL
Axle System
12 X 100
12 X 142
Brake Interface
Centerlock
Centerlock
Labyrinth system
Yes
Yes
Spokes
Front
Rear
Spoke count
21
24
Spoke type
Sapim CX-Ray
Sapim CX-Ray
